Yamaha MG10 Mixer

D-PRE CLASS-A PREAMPS: Four Yamaha D-PRE Class-A microphone preamps capture vocals and instruments with clean, natural sound and low noise

10-CHANNEL MIXING: Four mic/line inputs and six line inputs provide flexible connectivity for bands, podcasts, presentations, rehearsals, and live sound

1-KNOB COMPRESSORS: Instantly dial in balanced compression on channels 1 and 2 for smoother vocals and instruments with a single control

PHANTOM POWER READY: +48V phantom power supports condenser microphones, while the PAD switch helps prevent distortion from high-output audio sources

RUGGED METAL DESIGN: A durable metal chassis and balanced XLR outputs provide reliable performance and clean signal delivery for studio and live applications

The Yamaha MG10 is a compact 10-channel analog mixer built for dependable performance in live sound, rehearsals, podcasting, presentations, and recording setups. Four mono mic/line inputs equipped with Yamaha's renowned D-PRE Class-A microphone preamps capture vocals and instruments with clean, natural detail, while three stereo line channels provide flexible connections for keyboards, media players, and other audio sources.

Channels 1 and 2 feature Yamaha's 1-Knob Compressors, making it easy to control vocal and instrument dynamics without complex adjustments. +48V phantom power supports condenser microphones, and the integrated PAD switch helps manage high-output signals for clean, distortion-free operation.

Balanced XLR outputs deliver a reliable connection to powered speakers, amplifiers, or recording equipment, while the rugged metal chassis is built to withstand regular studio, rehearsal, and live use. If you need professional Yamaha audio quality without built-in effects or USB recording, the MG10 offers a straightforward mixing solution focused on dependable performance.

Key Specifications

Channels: 10 (4 Mono Mic/Line + 3 Stereo Line)
Preamps: Yamaha D-PRE Class-A
Compression: 1-Knob COMP (Channels 1 & 2)
Phantom Power: +48V
AUX Send: 1
Outputs: Balanced XLR
Construction: Metal Chassis
Dimensions: 9.6 × 2.8 × 11.6 in.
Weight: 4.19 lb
Color: Black

Outline
I/O: Phantom power: +48 V
Input Channels: Mono[MIC/LINE]: 4
: Stereo[LINE]: 3
Output Channels: STEREO OUT: 2
: MONITOR OUT: 1
: PHONES: 1
: AUX SEND: 1
Bus: Stereo: 1, AUX[FX]: 1
Input Channel Function: PAD: 26 dB (Mono)
: HPF: 80 Hz, 12 dB/oct (Mono)
: COMP: 1-knob compressor Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec
: EQ HIGH: Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving
: EQ MID: Gain: +15 dB/-15 dB, Frequency: 2.5kHz peaking
: EQ LOW: Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving
: PEAK LED: LED turns on when post EQ signal reaches 3 dB below clipping
: Level Meter: 2 x 7 -segment LED meter [PEAK, +10, +6, 0, -6, -10, -20 dB]
General specifications
Total harmonic distortion: 0.02 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +24dBu (1kHz), GAIN knob: Min
Frequency response: +0.5 dB/-1.0 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min
Hum & noise level: Equivalent input noise: -128 dBu (Mono Input Channel, Rs: 150?, GAIN knob: Max)
: Residual output noise: -102 dBu (STEREO OUT, STEREO LEVEL knob: Min)
Crosstalk: -83 dB
Power requirements: PA-10 (AC 38 VCT, 0.62A, Cable length = 3.6 m) or equivalent recommended by Yamaha
Power consumption: 22.9 W
Dimensions: W: 9.6" (w)
: H: 2.8" (h)
: D: 11.6" (d)
Net weight: 1.9 kg (4.19 lbs.)
Accessories: Included Accessory: AC Adaptor, Owner's Manual, Technical Specifications, Optional Accessory: Mic Stand Adaptor BMS-10A
Others: Operating Temperature: 0 to +40?C
